Ubiquiti UniFi Dream Machine Pro Max UDM-Pro-Max

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max Overview

The Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max is a high-performance 1U rack-mounted UniFi Cloud Gateway designed for medium-sized and large network deployments. It combines advanced routing, firewall security, VPN, SD-WAN, UniFi application management, high-speed networking, and professional NVR functionality in a single appliance.

Ubiquiti specifies support for 200+ managed UniFi devices and 2,000+ simultaneous connected users, making the UDM-Pro-Max considerably more capable than compact UniFi gateways intended for smaller networks. It also provides 5Gbps IDS/IPS throughput and 10G connectivity for high-performance network environments.

The UDM-Pro-Max is also designed for deployments that require surveillance storage and resilience. It has two 3.5-inch NVR HDD bays and an integrated 128GB SSD, while Shadow Mode provides gateway failover capabilities.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max Price in Kenya

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max Specifications

These specifications are based on Ubiquiti's current technical documentation.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max Networking Performance

The UDM-Pro-Max is built for high-throughput network environments where routing, security inspection, and centralized management need to operate together.

• Up to 5Gbps IDS/IPS throughput.

• 10G SFP+ connectivity.

• 2.5GbE RJ45 WAN connectivity.

• Eight Gigabit Ethernet LAN ports.

• Multi-WAN load balancing.

• LACP port aggregation.

• Advanced QoS.

• Advanced NAT.

• Policy-based WAN routing.

• Policy-based VPN routing.

• OSPF dynamic routing.

• BGP dynamic routing.

• Customizable DHCP.

• IPv6 ISP support.

• IGMP proxy.

• Multicast DNS.

• Internet quality monitoring.

The combination of 10G interfaces and 5Gbps IDS/IPS throughput makes the UDM-Pro-Max suitable for demanding wired networks and high-speed Internet connections.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max Connectivity and compatibility

The UDM-Pro-Max provides a mixture of Gigabit, 2.5GbE, and 10G interfaces for connecting different classes of network equipment.

• 1 × 2.5GbE RJ45 port.

• 8 × Gigabit RJ45 LAN ports.

• 2 × 10G SFP+ interfaces.

• Compatible with UniFi switches.

• Compatible with UniFi access points.

• Compatible with UniFi cameras through UniFi Protect.

• Compatible with UniFi Access equipment.

• Suitable for high-speed NAS connections.

• Suitable for 10G network uplinks.

• Suitable for multi-WAN deployments.

• Suitable for enterprise network infrastructure.

The UDM-Pro-Max can therefore serve as the central gateway for a broader UniFi ecosystem rather than simply functioning as a conventional Internet router.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max Firewall and Security

The UDM-Pro-Max provides advanced security controls for professional network environments.

• Stateful firewall.

• Application-aware Layer 7 firewall.

• Deep packet inspection.

• Traffic identification.

• Zone-based firewall.

• Region-based filtering.

• Domain-based filtering.

• Application-based filtering.

• Content filtering.

• Ad blocking.

• Intrusion prevention.

• Intrusion detection.

• VLAN-based segmentation.

• Subnet-based segmentation.

• Advanced security policies.

Ubiquiti specifies 55,000+ IDS/IPS signatures with CyberSecure, providing a broad signature base for threat detection and prevention.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max VPN and SD-WAN

The UDM-Pro-Max provides a wide range of secure remote-access and site-to-site networking options.

• WireGuard VPN.

• OpenVPN.

• IPsec VPN.

• L2TP VPN.

• Teleport zero-configuration VPN.

• Identity Endpoint one-click VPN.

• Site-to-site VPN.

• Site Magic SD-WAN.

• Policy-based VPN routing.

• License-free SD-WAN.

• OpenVPN client.

• WireGuard client.

These capabilities make the UDM-Pro-Max suitable for businesses operating multiple locations, remote users, branch offices, and distributed network environments.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max NVR and Storage

The UDM-Pro-Max provides built-in storage capabilities for UniFi Protect and other supported UniFi applications.

• 2 × 3.5-inch NVR HDD bays.

• Integrated 128GB SSD.

• Supports redundant NVR storage.

• UniFi Protect support.

• Local video recording.

• Centralized camera management.

• Surveillance storage expansion.

• Suitable for professional CCTV deployments.

Ubiquiti lists support for up to 50 HD cameras, 25 2K cameras, or 15 4K cameras, depending on the deployment.

The two HDD bays also provide greater storage flexibility than UniFi gateways with only a single storage bay.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max UniFi Application Support

The UDM-Pro-Max operates as a centralized UniFi application platform.

• UniFi Network for network management.

• UniFi Protect for surveillance.

• UniFi Access for access control.

• UniFi Talk for communications.

• UniFi Connect for compatible connected devices.

This allows multiple UniFi services to be managed from one professional rack-mounted appliance.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max High Availability

For organizations where network availability is important, the UDM-Pro-Max provides additional resilience features.

• Shadow Mode gateway failover.

• VRRP high availability.

• USP-RPS DC backup input.

• Redundant NVR storage.

• Dual NVR drive bays.

• Backup power compatibility.

• Professional rack-mounted deployment.

Ubiquiti specifically identifies Shadow Mode, VRRP gateway failover, and DC power backup as redundancy features of the UDM-Pro-Max.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max Design and build

The UDM-Pro-Max uses a professional 1U rack-mounted chassis designed for server rooms, network cabinets, and structured IT environments.

• 1U rack-mount design.

• Aluminium CNC and SGCC steel enclosure.

• SGCC steel mounting hardware.

• 442.4 × 43.7 × 285.6mm dimensions.

• Approximately 4.7kg weight.

• 1.3-inch touchscreen display.

• Internal power supply.

• Dedicated status LEDs.

• HDD activity indicators.

• RPS status indicator.

• Factory-reset button.

The rack-mounted design makes it suitable for centralized IT infrastructure where multiple networking and security components are installed in a dedicated cabinet.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max Power

The UDM-Pro-Max uses an internal power supply and can also accept a compatible DC backup connection.

• Universal 100–240V AC input.

• Internal 100W power supply.

• Maximum power consumption of 60W.

• USP-RPS DC input.

• Suitable for continuous network operation.

• Supports additional power redundancy.

• Designed for rack-mounted environments.

The maximum specified system power consumption is 60W, while the internal power supply is rated at 100W.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max Ideal Use Cases

• Medium-sized businesses

• Large offices

• Corporate networks

• Hotels

• Schools and institutions

• Retail networks

• Multi-site organizations

• Security and surveillance deployments

• Professional network infrastructure

• High-speed Internet environments

• 10G network environments

• UniFi Protect installations

• UniFi Access deployments

• Enterprise VPN deployments

• Data-intensive network environments

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max FAQs

1. What is the Ubiquiti UniFi Dream Machine Pro Max?

The UDM-Pro-Max is a 1U rack-mounted 10G UniFi Cloud Gateway that combines advanced routing, firewall security, VPN, SD-WAN, UniFi application management, and NVR functionality.

2. How many UniFi devices can the UDM-Pro-Max manage?

Ubiquiti specifies support for 200+ managed UniFi devices and more than 2,000 simultaneous connected users.

3. What is the IDS/IPS throughput?

The UDM-Pro-Max provides up to 5Gbps IDS/IPS throughput according to Ubiquiti's technical specifications.

4. Does the UDM-Pro-Max support 10G networking?

Yes. It provides two 10G SFP+ interfaces, suitable for high-speed WAN, LAN, and network uplink applications.

5. How many NVR drives can it hold?

The UDM-Pro-Max has two 3.5-inch NVR HDD bays and an integrated 128GB SSD.

6. Does it support UniFi Protect?

Yes. UniFi Protect is part of the supported UniFi application suite, making the device suitable for centralized camera management and recording.

7. Does the UDM-Pro-Max support VPN?

Yes. It supports WireGuard, OpenVPN, IPsec, L2TP, Teleport, and Site Magic SD-WAN functionality.

8. Is the UDM-Pro-Max suitable for large networks?

Yes. Ubiquiti positions it for larger deployments, with support for 200+ UniFi devices and 2,000+ clients. Ubiquiti's guidance specifically identifies the UDM-Pro-Max for mid- to large-scale deployments.

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max Pros and Cons

Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max Conclusion

The Ubiquiti UniFi Dream Machine Pro Max-UDM-Pro-Max is a high-performance UniFi Cloud Gateway designed for organizations that need advanced networking, security, surveillance, and centralized infrastructure management in a professional rack-mounted platform.

With 5Gbps IDS/IPS throughput, 10G SFP+ connectivity, 2.5GbE WAN, support for 200+ UniFi devices and 2,000+ users, dual NVR HDD bays, 128GB integrated SSD storage, advanced VPN and SD-WAN features, and gateway failover capabilities, it is well suited to medium-sized and large UniFi deployments.
